破解光猫超级用户密码

首先我强调光猫型号为HS8545M5，软件版本为V5R020C00S200；

由于需要光猫出场时默认为路由模式，我需要将其修改为桥接模式，而光猫背面的user用户没有权限修改，因此需要获取超级用户权限。

光猫telnet使能

光猫没有开启telnet服务，需要工具进行破解，破解工具的下载链接在最后；

先下载破解工具，接着拔掉光纤，重启光猫，通过宽带线把电脑与光猫连接，打开ONT维修使能工具；

选择维修使能，点击刷新，然后启动; 当“当前成功总数”变为1后，点击停止，结果类似下面截图;

打开命令行，测试telnet能否连接成功，当出现找不到命令时，开启windows的telnet服务;

1
telnet 192.168.1.1

然后输入用户名root;密码尝试下Hw8@cMcc或者adminHW,成功的话结果如下：

获取用户名及密码密文

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
WAP>su
success!
SU_WAP>shell

BusyBox v1.30.1 () built-in shell (ash)
Enter 'help' for a list of built-in commands.

profile close core dump
WAP(Dopra Linux) # ls
bin      dev      init     linuxrc  root     sys      var
boot     etc      lib      mnt      sbin     tmp
bundle   html     libexec  proc     share    usr
WAP(Dopra Linux) # cd /mnt/jffs2/
WAP(Dopra Linux) # ls
CfgFile_Backup         dypack_debug           mount_ok
CfgwithoutlineD        factory_file           mount_osgi_ok
DHCPlasterrwan1        fsok                   nffruntimes
DHCPlasterrwan5        ftvoipcfgstate         oldcrc
FTCRC                  hard_version           onlinecounter
InformFlag             hw_boardinfo           ontstatusfile
TelnetEnable           hw_boardinfo.bak       optic_init_par.bin
Updateflag_bak         hw_bootcfg.xml         ppplasterr258
UpnpExpandFirstInit    hw_ctree.xml           ppplasterr259
V5_TypeWord_FLAG       hw_ctree_bak.xml       reboot_bind_tag
app                    hw_default_ctree.xml   reboot_info
asan_test              hw_default_ctree2.xml  recovername
backup_ok              hw_hardinfo_feature    request_ddr
board_type             hwflashlog.bin         request_ddr_inner
bob_type               hwkeyinfogetlog.bin    resetkey
ceaseadv.conf          hwnfflog.bin           restore
certs                  hwontdebuglogctrl.bin  result_ddr
customize              hwontdebuglogdata.bin  scflie_0
customize.txt          hwontlog.bin           scflie_1
customizepara.txt      keyreleasecount.txt    smooth_finish
cwmp_rebootsave        kmc_need_backup        typeword
dhcp6c                 kmc_store_A            upgrade_info.xml_back
dhcp_data_a            kmc_store_B            xmlcfgerrorcode
dhcp_lastip            lastsysinfo.tar.gz
dhcpc                  main_version
WAP(Dopra Linux) # cp /mnt/jffs2/hw_ctree.xml /mnt/jffs2/mycfg.xml.gz
WAP(Dopra Linux) # aescrypt2 1 mycfg.xml.gz tem
WAP(Dopra Linux) # gzip -d mycfg.xml.gz
WAP(Dopra Linux) # grep WebUserInfoInstance mycfg.xml
<X_HW_WebUserInfoInstance InstanceID="1" ModifyPasswordFlag="0" UserName="user" Password="$2sN}QKqrgY(,w8^GHpW7)$|L3MQ)tWIkZv5Na2Z1E$" UserLevel="1" Enable="1" Alias="cpe-1"/>
<X_HW_WebUserInfoInstance InstanceID="2" ModifyPasswordFlag="1" UserName="CMCCAdmin" Password="$2I3^R(k3[.)B9I4E8:S!DF!Q$ULd6S(U7RRH^2]2-=Nxs&amp;S`J6))+2$S8&quot;&apos;j&amp;$" UserLevel="0" Enable="1" Alias="cpe-2" PassMode="0"/>
WAP(Dopra Linux) #
success!
SU_WAP>

找到关键字user与password部分;

上图中CMCCAdmin用户密码密文为：$2I3^R(k3[.)B9I4E8:S!DF!Q$ULd6S(U7RRH^2]2-=Nxs&S`J6))+2$S8"'j&$

打开华为二次密码破解工具S1S2语音全鉴密.zip中的huawei.exe，在密文解密中输入，尝试3种解密，得出密码为CMCCAdminFf2IrXFt

使用超级用户登录光猫

用户名CMCCAdmin，密码CMCCAdminFf2IrXFt，发现可以修改连接模式了;

文件链接：https://pan.baidu.com/s/101GrTj53T4RaIpc0h4KAoQ

提取码：adja

参考

https://www.eaglemoe.com/archives/216

2022-06-18 更新
